| Color Coded Pivots & Points of Adjustment |
Yes |
|
User Adjustment Range |
7 position seat, 6 back pad positions with a total range of 20 degrees (4 degrees per position) |
|
Machine Assisted User Adjustments |
Spring assisted seat, gas assisted back pad |
|
Available Frame Colors |
Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium |
|
Frame Finish |
Proprietary two-coat powder process |
|
Cable Transmission |
Internally lubricated cables & fittings |
|
Integrated Leveling System |
Yes, top-down leveler |
|
Machine Anchoring |
Independent machine hold down brackets |
|
Overall Static Dimensions (L x W x H) |
140 x 141 x 135 cm / 55" x 55.4" x 53" |
|
Overall In-Use Dimensions (L x W x H) |
168.5 x 141 x 135 cm / 66.3" x 55.4" x 53" |
|
Rep Counter Battery Life |
Approximately 3 years |
|
Rep Counter Power Supply |
2 AA batteries |
|
Rep Counter Machine Usage Tracking |
Service mode tracks total machine reps and hours of use |
|
Product Weight |
348 kg / 768 lb |
|
Rear Placards |
Color-coded machine identification, exercise specific stretching |
|
Personal Storage |
Two tactile storage mats, personal device cradle and towel hook |
|
Contoured Seat |
Yes |
|
Foot Platform |
Foot rest for comfort during exercise |
|
Action Specific Grips |
Exercise specific grips improving feel, function and form during use |
|
Front Placards |
Muscle call outs, exercise specific stretching, start & finish exercise illustrations, proper machine adjustments, color-coded machine identification |
|
Rep Counter |
Electronic counter displays reps, exercise time and rest time |
|
Placard Color Coding |
Yellow (upper body) |
|
Weight Plate Increments |
4.5 kg / 10 lb |
|
Total Stack Weight |
108 kg / 240 lb |
|
Weight Stack Guarding |
Full front and rear shields |
|
Consistent 53" Stack Height |
Yes |
|
Max Training Weight |
111.4 kg / 247.5 lb |
|
Incremental Weight System |
1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lb |
